Congelador rápido de la placa del congelador de la ráfaga de congelación rápida de los pescados
- precio
- US $80000
- modelo
- Serie FH
- MOQ
- 1 set
propiedad
- Refrigerante
- Freón
- Estructura
- Montado
- Adecuado para
- Fábrica
- Sistema de refrigeración
- Unidad de compresor de marca
- tamaño
- Personalizado
- Usa la naturaleza
- Producción
- Uso
- Vegetales y frutas
- Material del cuerpo del congelador
- Acero inoxidable 304
- Especificación
- CE ISO9001
- Paquete de transporte
- Caso de madera contrachapada marinero
Evaluacion
Descripción
Products Description
1, Plate freezer has Quick freezing speed, high efficiency, low power consumption, good sanitary conditions, small occupied area, the advantages of operating at room temperature
2, Plate freezer Suitable for fishing, seafood products, food, business, trade and other frozen processing industry. Processing a variety of fish, shrimp, shellfish and other aquatic products and meat food in small package.
3, Plate freezer use Aluminum alloy freezing plate adopts extruded aluminum magnesium alloy special, light weight, high degree of finish, reasonable structure, good thermal conductivity, corrosion resistance
Parameters list
Model Item | Capacity (kg) | Plate Quantity | Distance between(mm) | Dimension of plate(mm) | Refrigerating Capacity(kw) | Install power Compressor unit | Overall dimension (L*W*H)(mm) | Refrigerant | Weight(kg) |
FST-500 | 500 | 10 | 55~100 | 1200*1260 | 23 | S6G25.2Y compressor | 3500*1900*2000 | R404a | 2400 |
FST-1000 | 1000 | 10 | 55~105 | 2000*1260 | 45 | 2*S6G25.2Y compressor | 4300*1900*2900 | R404a | 3800 |
FST-1300 | 1300 | 14 | 55~100 | 2000*1260 | 60 | HSN7461-70Y compressor | 4300*1900*3200 | R404a | 4800 |
FST-1540 | 1540 | 11 | 55~105 | 2000*1670 | 65 | HSN7471-75Y compressor | 3300*2100*2900 | R404a | 5000 |
FST-2002 | 2000 | 14 | 55~100 | 2000*1670 | 76 | 2*HSN6451-50compressor | 3300*2100*3200 | R404a | 6000 |
