Almacenamiento en frío / sala de verduras frescas y carne / pescado
Almacenamiento en frío / sala de verduras frescas y carne / pescado
Almacenamiento en frío / sala de verduras frescas y carne / pescado
Almacenamiento en frío / sala de verduras frescas y carne / pescado
Almacenamiento en frío / sala de verduras frescas y carne / pescado
Almacenamiento en frío / sala de verduras frescas y carne / pescado
precio
US $50000
modelo
FST-LK
MOQ
1 set

propiedad

Refrigerante
Freón R22 (R404A) para la selección
Estructura
Montado
Adecuado para
Fábrica
Sistema de refrigeración
Unidad de compresor de marca
Uso
Congelador fresco, congelado, congelador
Sistema de refrigeración
Unidad de compresor de marca
Paquete de transporte
Embalaje marinero
Servicio postventa
Servicio de asistencia

Evaluación de producto

Descripción

Cold room Specification
1. Compressor
2. Danfoss Parts
3. PU  insulation sandwich panel board

4. Air cooler

Condenser
Feature of freezer cold rooms ,refrigerated chiller and freezer ,cold room /chiller room, cold storage room, cooler room,Cold storage /cold store/ walk in freezer room / cold room, cold storage room, chiller room, cooling room:
Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. Portable sliding doors, and out of cold storage more convenient, easy to operate.
Water defrosting evaporator defrost faster, save operating costs.
Cold storage door with anti-shock protection, an increase of reliability.
Projects
(1) Temperature range: -40ºC~+20ºC are all available.
(2) Size: Customize.
(3) Functions: fresh-keeping, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available.
(4) Fully automatic control system.
(5)Easy to install and dismantle
(6) Temperature Alarm
(7) Data Logger
(8)PLC electric control ( LG,SIMENS, OMRON..famous parts)
(9) Refrigerant:R22,R404A

Evaporator type

Air Cooled Type

Ceiling type  DL (5-20℃DD-5~+5 ℃DJ-18~-20℃

Aluminum shelving

Customize -18 ℃ or -35℃

Evaporator Cooled Type

Evaporator Condenser DJS (-30~-40)

Room size type

Room size

Mini

Small

Middle

Big

Volume range

200m³

200~1000

1000~5000

>5000

Temperature table for reference

Cold storage goods

Temperature range

Processing room

10

Fruit, vegetable, dry food

0~-5

Medicine, cake, pastry, chemical material

0~-5

Ice storage room

-5~-10

Fish, meat storage

-18~-25

Deep freezer.

-25C~-35

Compressor type and condenser

Compressor type

Bitzer(Germany)

Frascold (Italy)

Copeland (US)

China brand

Condenser

Air cooled

Aater cooled

Evaporator



Panels information

Office Foam panel

50mm thickness

Processing room 10

50mm/ 75mm PU

-5

75mm/ 100mm PU

-18

100mm/ 150mm PU

-25C/ -35

150mm/200mm PU

Panel steel cover

SS, GI, aluminum etc
